Uses: Suitable for city buildings, suburban villas, houses, water and pressurized with industrial equipment, air conditioning, boilers, solar circulating water, hot water circulating warm and so on.
Advantages: no leakage, low noise, environmental protection, aesthetics, ease of installation and so on.
Suitable fluids:
Heating water to cdi 2035
Water/glycol mixtures max mix. ing ratio 1:1
Hydraulic corrections required for mixing ratio above 20%
Performance:
Speed range 1100-2800r.p.m. Manual 3-speed control
Fluid temperature range -10”ę £ +110 ”ę Max.working pressure 10bar
Ambient temperature:
Permissible up to 40”ę
Power:
Mains power 110/220V ,50/60HZ
Motor:
Degree of protection IP44 Insulation class H
|
| ”””” Model Defination |
 |
”¤Pump body: cast iron/brass.
”¤Impeller: GF-PP.
”¤Shaft: stainless steel /ceramic. |
|
| Technical Data |
model |
power(w) |
Voltage(v) |
Frequency(Hz) |
Inlet/Outlet (IN) |
Highest Head(m) |
Max.Capacity (L/min) |
G.W.
(kg) |
SPS15-90Z |
100 |
110/220 |
50/60 |
G 3/4" |
9 |
23 |
2.8
|
SPS15-110Z |
120 |
110/220 |
|
G 3/4" |
11 |
26 |
3.2
|
SPS20-130Z |
248 |
110/220 |
|
G 1 |
13 |
52 |
5.0 |
|
|
.jpg)
